3 Ton Portable Gantry Crane, Steel & Aluminum Portable Gantry
3 ton portable gantry crane for sale. Types of portable gantry crane 3 ton for sale, steel & aluminum portable gantry crane designs.Get your 3 ton gantry.
| Crane Type | 3 ton portable gantry crane in steel or lightweight aluminum construction; adjustable or fixed-height frame; manual/electric trolley with chain or wire rope hoist; ISO A3–A5 / FEM 1Am–3M duty class; 380/400/415V, 50Hz, 3Ph for electric systems; |
| Crane Capacity | Up to 3 ton rated lifting capacity; steel construction is suitable for heavier-duty applications, while aluminum construction is selected where low dead weight and easy relocation are priorities. |
| Span Length | Typically 2–6 m span; customized according to load, frame material, mobility, and required working area. |
| Lifting Height | Typically 2–5 m; adjustable or fixed lifting height available according to application and available headroom. |
| Coverage Area Type | Mobile or localized rectangular coverage within the gantry frame; workshops, machine areas, assembly stations, maintenance areas, warehouses, loading zones, and temporary lifting points. |
| Application | Workshop lifting, machinery maintenance, equipment installation, assembly, machine loading and unloading, warehouse handling, repair work, and temporary lifting operations. |
| Certifications | CE / ISO / SGS / Other third-party inspection |
| Customization | Customized 3 ton capacity, span, lifting height, steel or aluminum frame, adjustable or fixed height, wheel/caster arrangement, electric chain or wire rope hoist, manual/electric trolley, pendant or radio remote control, and application-specific lifting a |
Crane Manufacturer: Yuantai Cranes – 30+ Years Professional Crane Manufacturer from China
Category: Portable Gantry Crane Drawings
Tags: 3ton
Your Trusted Overhead Gantry Crane Manufacturer & Supplier
3 Ton Portable Gantry Crane, Steel & Aluminum Gantry
Custom Portable Gantry Crane 3 Ton for Sale Good Price
3 ton portable gantry crane for sale. Types of portable gantry crane 3 ton for sale, steel & aluminum portable gantry crane designs.Get your 3 ton gantry.
Yuantai Cranes
Yuantai Cranes - Global Material Handling Crane Solution Provider & Manufacturer with CE, ISO, SGS, CNEX and other Third Party Certifications.
- Main Specifications - Capacity: 0.5–550 tons | Span: up to 40m | Speed: 0.8–12 m/min | Duty: A3–A7 | Power: 380–690V, 50/60Hz | Control: pendant/remote/cabin
- Full engineering: FEA/PLC/VFD + in-house build + global delivery + on-site support, for workshops, factories, EPC contractors, industrial projects, etc.
- Support: design, manufacturing, testing, service – end-to-end, customized lifting solutions worldwide.
Get Your Custom Quote – Quick & Easy
Fill in what you know. Skip what you don't – we'll help.
- Crane type:_____ . (e.g., overhead crane, gantry crane, jib crane)
- Max weight to lift:_____ tons. (e.g., 2t, 5t, 10t, 20t, 50t)
- Lifting height:_____ m. (How high does the hook need to reach?
- Workshop width (span):_____ m . (Distance between the two crane rails)
- Travel distance:_____ m . (How long does the crane need to move along the runway?)
- Control type:_____. (Pendant / remote / cabin Control)
- Power supply:_____. (Local voltage & frequency – e.g., 380V, 50Hz, 3-phase)
- What will it be used for?_____ (e.g., steel fabrication, concrete products, mold handling, general manufacturing, etc.)
- Any special requirements?_____ (e.g., extreme temperature, dusty or explosive environment, special paint color, etc.)
Just leave a message via the contact form and our hoist and crane engineer will contact you with in 24working hours.
Inquire Yuantai Cranes
