2 Ton Portable Gantry Crane, 2 Ton Telescoping Gantry & Fixed Height
2 ton portable gantry crane for sale. Types of portable gantry crane 2 ton for sale, with fixed height & adjustable gantry crane designs. Get custom design now.
| Crane Type | 2 ton portable gantry crane for 2,000 kg load handling; telescoping or fixed-height steel frame; electric chain/wire rope hoist or manual hoist; manual/electric trolley; ISO A3–A5 / FEM 1Am–3M; 380/400/415V, 50Hz, 3Ph for electric systems; |
| Crane Capacity | 2 ton (2,000 kg) rated lifting capacity for handling loads up to 2 tons, subject to the selected hoist, span, lifting height, duty class, and operating conditions. |
| Span Length | Typically 2–5 m span; customized according to the 2 ton load size, load center, working space, and required lifting coverage. |
| Lifting Height | Typically 2–5 m; telescoping models allow height adjustment, while fixed-height models are designed for a specific lifting height. |
| Coverage Area Type | Localized mobile lifting coverage within the gantry frame; machine areas, workstations, workshops, assembly stations, maintenance areas, warehouses, loading zones, and temporary lifting points. |
| Application | Lifting and moving 2 ton machinery, motors, pumps, molds, equipment, steel parts, pallets, and maintenance loads in workshops, warehouses, assembly areas, and loading zones. |
| Certifications | CE / ISO / SGS / Other third-party inspection |
| Customization | Customized for 2 ton load handling with adjustable or fixed lifting height, telescoping or fixed-height frame, suitable span, electric chain/wire rope hoist, manual/electric trolley, pendant or radio remote control, and application-specific lifting attach |
Crane Manufacturer: Yuantai Cranes – 30+ Years Professional Crane Manufacturer from China
Category: Portable Gantry Crane Drawings
Tags: 2ton
Your Trusted Overhead Gantry Crane Manufacturer & Supplier
2 Ton Portable Gantry Crane for Sale
Custom 2 Ton Telescoping Gantry & Fixed Height Gantry Crane
2 ton portable gantry crane for sale. Types of portable gantry crane 2 ton for sale, with fixed height & adjustable gantry crane designs. Get custom design now.
Yuantai Cranes
Overhead Crane Manufacturer with CE, ISO, SGS, CNEX Certificates.
- Main Specifications - Capacity: 0.5–550 tons | Span: up to 40m | Speed: 0.8–12 m/min | Duty: A3–A7 | Power: 380–690V, 50/60Hz | Control: pendant/remote/cabin
- Full engineering: FEA/PLC/VFD + in-house build + global delivery + on-site support, for workshops, factories, EPC contractors, industrial projects, etc.
- Support: design, manufacturing, testing, service – end-to-end, customized lifting solutions worldwide.
How to Get an Accurate Crane Price for Your Application?
Tips: Copy the spec list, fill in your details, and paste it into the form on the right/ down-below for a quick price.
- Crane type:_____ . (e.g., overhead crane, gantry crane, jib crane)
- Max weight to lift:_____ tons. (e.g., 2t, 5t, 10t, 20t, 50t)
- Lifting height:_____ m. (How high does the hook need to reach?
- Workshop width (span):_____ m . (Distance between the two crane rails)
- Travel distance:_____ m . (How long does the crane need to move along the runway?)
- Control type:_____. (Pendant / remote / cabin Control)
- Power supply:_____. (Local voltage & frequency – e.g., 380V, 50Hz, 3-phase)
- What will it be used for?_____ (e.g., steel fabrication, concrete products, mold handling, general manufacturing, etc.)
- Any special requirements?_____ (e.g., extreme temperature, dusty or explosive environment, special paint color, etc.)
Just leave a message via the contact form and our hoist and crane engineer will contact you with in 24working hours.
